LL83RA

Simple designed lock of RFID proximity method.

· Model type

• Battery (Alkaline AA battery 3ea, life : about 12months) : LL83RA

· Compatible door thickness

• 10 ~ 30mm

· Authentication method & Emergency power

• 3 level key management (Owner > Master > User)
• Owner : RFID 1ea
• Master : RFID (Up to 20ea)
• User : RFID (Up to 20ea)
• Cleaner : RFID (Up to 20ea), Option
• Emergency power : 9v Battery
• RFID spec : 13.56Mhz, ISO 14443A

· Product information

• RFID Key proximity method
• Small size, Simple design
• Auto locking
• Melody & ICON status LED

· Usage

• Office, School, Public company, Individual, Security solution company, lock manufacturer, etc

· Specification

• Rear size : 66mm(W) * 122mm(H) * 27.7mm(T)
• Front size  : 52mm(W) * 93mm(H) * 17mm(T)
• Rear color : Brown
• Front color : Gold / Silver
• Material : PC/ABS Alloy
