LL92AR | UNILOCK

High class digital locker lock on RFID Key proximity type which support Network & Online power

· Model type

Online power type : LL92ARE
Network type : LL92ARN

· Compatible door thickness

A : 15~20mm
B : 20~25mm
C : 25~30mm

· Authentication method & Emergency power

3 level key management (Owner > Master > User)
Owner : RFID
Master : RFID (Multiple key)
User : RFID
Cleaner : RFID
RFID Spec : 13.56Mhz, Mifare Classic, Mifare Ultralight, Mifare DESFire/EV1

· Product information

Circle handle design
RFID key proximity method

· Usage

Storage box, filing cabinet, locker, etc

· Specification

Rear size : 66mm(W) * 106mm(H) * 27.5mm(T)
Front size : 66mm(W) * 98mm(H) * 29.2mm(T)
Rear color : Dark Gray
Front color : Dark Gray
Material : PC/ABS Alloy
